Model |
BM 50 |
BM 50C |
|
Engine brand |
HONDA GX270 |
CHANGFA CF178 |
|
Engine model |
Gasoline, single cylinder, vertical, four stroke, OHV |
Diesel, single cylinder, vertical, four stroke, direct injection |
|
Cooling |
Air-cooling |
|
|
Power(HP/KW) |
9.0/6.7 |
6.0/4.4 |
|
Ratating speed |
3600rpm |
|
|
Fuel capacity(L) |
5.9 |
2.7 |
|
Lubricating oil(L) |
1.1 |
|
|
Start up |
Recoil hand start |
|
|
Static load |
45N/CM |
|
|
Vibration frequency(HZ) |
70 |
|
|
Nominal amplitude(MM) |
0.6 |
|
|
Exciting force(KN) |
20 |
|
|
Walking way |
Two-way hydraulic&chain drive |
|
|
Walking speed(KM/H) |
0-3.8 |
|
|
Climbing ability |
30% |
|
|
Hydraulic tank capacity(L) |
18 |
|
|
Water tank capacity(L) |
20 |
|
|
Watering system |
Gravity watering |
|
|
Steel wheel size(MM) |
426×600*2 |
|
|
Total length(MM) |
2480 |
|
|
Total width(MM) |
780 |
|
|
Total height(MM) |
1820 |
|
|
Packing size(MM) |
1600*850*1900 |
|
|
weight (KG) |
650 |
|
