| Item No./Details | BM1800 | |
| DRIVE | ||
| Engine | HONDA GX630 | YANMAR 3TN68 |
| Engine type | Four-stroke, air-cooled, gasoline engine, OHV | Four-stroke, water-cooled, diesel engine, in line and V-type |
| Number of cylinders | 2 | |
| Output Power (KW) | 12 | 14 |
| Rating Speed(rpm) | 3600 | |
| Electrical equipment(V) | 12 | |
| Drive mode | Variable displacement pump, stepless speed change, two wheels | |
| WALKING CHARACTERISTICS | ||
| Walking speed (KM/h) | 0-8 | |
| Theoretical climbing ability | 30% | |
| STEERING | ||
| Steering mode | Hydraulic steering | |
| Steering system | Swing articulated | |
| EXCITATION SYSTEM | ||
| Vibration wheel | Before | |
| Drive form | Hydraulic motors | |
| Vibration frequency (HZ) | 65 | |
| Vibration amplitude (MM) | 0.6 | |
| Exciting force(KN) | 25 | |
| BRAKE | ||
| Working brake | Variable displacement pump | |
| SPRINKLER SYSTEM | ||
| Water spray form | Intermittent pressure water spray | |
| CAPACITY | ||
| Hydraulic oil capacity(L) | 30 | |
| Fuel capacity(L) | 30 | |
| Water tank capacity (L) | 60L | |
| SIZE | ||
| Working width(MM) | 960 | |
| Overall length(MM) | 2075 | |
| Machine Height(MM) | 1595 | |
| Turning radius(outer)(MM) | 2800 | |
| Drum size | 560*900mm*2 | |
| Wheel track(MM) | 1450 | |
| WEIGHT | ||
| Weight(KG) | 1350 | 1370 |
